Mini2Plus for Android
Make your phone smarter with HIKMICRO thermal camera
- uper Clear Thermal Image
- 25 Hz Smooth Video
- Accurate Temperature Measurements
- Mini Size
- Plug and Play
|
|
|
| Mini2Plus | |
| Infrared Image | |
| IR Resolution | 256 × 192 (49,152 pixels) |
| NETD | < 40 mK (@ 25 °C, F#=1.0) |
| Image Frequency | 25 Hz |
| Detector Pitch | 12 μm |
| Spectral Range | 7.5 to 14 μm |
| Focal Length | 6.9 mm |
| F-number | F1.0 |
| Field of View (FOV) | 25° × 18.8° |
| Focus Mode | Manual Focus |
| Image Modes | Thermal |
| Color Palettes | White Hot, Black Hot, Rainbow, Ironbow, Sepia, Color, Ice Fire, Rain, Red Hot, Green Hot, Dark Blue, Combined |
| Measurement and Analysis | |
| Object Temperature Range | -20°C to 350°C(-4°F to 662°F ) |
| Accuracy | Max (±2°C/3.6°F, ±2%), for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F) |
| Measurement Tools | Center Spot, Hot Spot, Cold Spot User-definable: 3 spots, and 3 rectangles. |
| Level and Span Mode | Auto/Manual |
| Protection Level | IP40 |
| Drop Test Height | 1 m (3.28 ft) |
| Working Temperature Range | -10°C to 50°C (14°F to 122°F ) |
| Storage Temperature Range | -20°C to 60°C (-4°F to 140°F ) |
| Weight | Approx. 24 g (0.053 lb) |
| Dimension | 26.6 × 26.6 × 25 mm (1.05 × 1.05 × 0.98 in) |
